This plugin for “Bohemian Coding Sketch” is generating Qr Codes with different error correction level. Raising this level improves error correction capability, but also increases the size of QR Code. The default value of matrix size is 21×21, but it can be increased if encoded text is too large. The default ECC level is 4 which means that 30% of codewords can be restored (codeword is a unit that constructs the data area. One codeword of QR Code is equal to 8 bits).
As its final result the script returns vector QR Code in the new artboard. And thanks to ECC Feature 30% of the QR Code space can be occupied by your logo or picture.
Examples of using QR Codes
Just put any of this code into dialog window:
Contact info (recommended):
MECARD:N:Owen,Sean;ADR:76 9th Avenue, 4th Floor, New York, NY 10011;TEL:12125551212;EMAIL:email@example.com;;
BIZCARD:N:Sean;X:Owen;T:Software Engineer;C:Google;A:76 9th Avenue, New York, NY 10011;B:+12125551212;E:firstname.lastname@example.org;;
BEGIN:VCARD\\N:Gump;Forrest\\TITLE:Shrimp Man\\TEL:(404) 555-1212\\ADR:100 Waters Edge;Baytown;LA;30314;United States of America\\EMAIL:email@example.com\\END:VCARD
Wifi Network config (Android):
- more information you can find in documentation…
Nov 08, 2016 - Sketch 41 support June 22, 2016 - Sketch 3.8 support February 4, 2016 - Sketch 3.5 support December 3, 2015 - Initial release
The word ‘QR Code’ is registered trademark of DENSO WAVE INCORPORATED
